Cold and hot water feeding pipe in nanometer anti-virus PP- R, PE, PEX material production line

Special single screw extruder for polyolefin, having high extruding velocity and effective plasticization.
Separation mixing screw specialized for polyolefin .
Specially designed three co-extruding die, reasonable channel, smooth outside and inside wall, and little internal stress.
Producing pipe limit Φ 20-Φ 160mm ,manufacture velocity up to 16 m/min .
May be used to produce HDPE silicon core tube, ordinary PP-R, PE and PEX pipes.
Low cost: The cost of nanometer & anti-virus pipe is merely increase 5-10% on the ordinary pipe basis.

Extruder	SJ-65/30B	SJ-90/30B
	SJ-45/30B	SJ-65/30B
	SJ-25/25B	SJ-25/25B
Pipe die	φ20-63	φ20-160
Sizing trough	SGZL-75	SGZL-160
Cooling trough	SGPL-75	SGPL-160
Haul off machine	SLQ-75B	SLQ-160B
Sawing machine	SLY-75	SLY-160
Stacker	F2-6	F2-6
